图象传感器\Image Sensor

1/3〞SONY CCD

有效像素\Effective Pixels

PAL:512(H)×582(V) NTSC: 512(H)×492(V)

信号系统\Signal System

PAL/NTSC

水平清晰度\Horizontal Resolution

420TV lines

快门速度\Shutter Speed

1/50(1/60)—1/100,000sec

白平衡\White Balance

Auto white balance

信噪比\S/N Ratio

More than 48db(AGC OFF)

**照度\Minimum Illumination

0Lux At Night(LED ON)

视频输出\Video Output

1.0Vp-p,75Ω

背光补偿\Backlight Compensation

ON

电源供给\Operation Temperature

AC220V/50HZ

工作温度\Operation Temperature

-10℃~+50℃ RH95％Max

同步方式\Sync System

Internal Synchronization

红外灯数量\LED number

Φ30 6PCS

红外灯距离\Infraed Lamps

100m
